Tutorial series: Sketching fundamentals
What you'll learn
Do you want endpoints to automatically adjust when a connected geometry is edited? Or make sketches symmetrical? Get tips for working with coincidence and symmetry constraints to set the relationship between sketch elements upfront and model more precisely.
Transcript
00:00
To bring this exercise to an end, I would like to finish with a few more tips about how to work with the grid and specifically the guide system. You see that the grid currently is turned off. I'm in Top View. Let's go to Sketch. The line command is turned on and I just draw a line. And I press Escape two times to exit the Sketch tool.
00:29
This point now, I would like to move vertically up and down, but you see it's not aligned to the grid. But look at these magenta lines. I can along these magenta lines, move this point vertically or horizontally. To extend or shorten this line, the same point, I simply move along the line's own direction to make it longer or shorter.
00:58
It's that easy. Let's add another line and escape, escape. And now this endpoint, I would like to be right where these two lines would intersect. I can extend this line, but I don't know where this would intersect with the other line. But take a look at this. I bring this to the endpoint.
01:27
And then wait a second, drag this out and there these two lines would intersect. And when I release the mouse button to that endpoint, a coincident constraint is being added. And that's actually very nice in Shapr3D. What this means now is when I move this point, you see the other line actually will follow to delete that constraint. We can simply select it and delete it.
01:57
Let's delete everything. I will go to the arc and create an arc. There we are. Then I create a line to here and press Escape and Escape. I would like this endpoint to snap onto kind of like the circle. This arc basically defines. So I can select this endpoint, move up.
02:27
Go to the circle and there it is. And release the mouse button. And here again, the same thing. If I zoom out a little bit, and for example, I change the point here, we see it runs through the end point of the line. If I move this, this drags the circle. If I drag the circle,
02:55
it's dragging then actually the line. So this is really very, very useful how this works in Shapr3D with the Constraint system. Let's take a look at how we can create patterns and symmetry. Both are very easy. Before we continue, I turned on the grid snapping actually. Let's go to the line command and I create a vertical line and press Escape.
03:24
then another line and escape, and a third line and escape and escape. So the center line, that's going to be our mirror or symmetry axis. So I turn this into a construction line and lock it so it can't move. These two points, I would like to be symmetrical to each other. So I select them, go to symmetry, and then I select the axis. And you see now when I move this,
03:53
these two points are in sync. We can do the same with the other two points. And now also those are in sync. Because all the points are symmetrical, that also means these two lines are equal in length.
