Settings or Preferences is where you can view your Shapr3D software version and set up or update your preferred settings for Shapr3D such as account settings, navigation preferences, and Sync.
WindowsiPadOSmacOS
Access Settings
You can access Settings through any of the following ways:
From the Dashboard, select Settings.
From the modeling space, go to File > Settings.
Shapr3D Settings
General
Single Key Action
Command Search – Uses Command Search as your single key action.
Hotkeys – Uses Hotkeys as your single key action.
Customize keyboard shortcuts – Opens the Keyboard Shortcuts settings.
Show Menu Button Labels – Choose your preferred way to display the menu button labels:
Always – Menu labels are always displayed.
On Hover, On All Buttons – The menu labels only display upon hovering your pointer.
Only for HoveredButtons – Only the hovered button displays the menu label.
Undo/Redo Button Position – Choose Title Bar or Bottom Bar as your preferred placement for the Undo and Redo buttons.
Reverse Zoom Scroll Direction – Toggle to enable reverse zoom scroll direction. Note: If you're using a keyboard, visit Navigation Presets for more navigation controls.
Start Shapr3D with – Select the screen that appears when you launch Shapr3D: Recents, Projects.
Theme – Choose your preferred theme: System, Light, Dark.
Accent color – Choose your preferred accent color.
Language – Choose your preferred supported language.
Tutorial Mode
Display clicks – Enable to display pointer clicks while modeling.
Display keyboard presses – Enable to display keyboard presses while modeling.
App Version – Check your software version.
Sync
Sync Across Devices – Toggle to enable or disable Sync.
Sync Projects – Appears when Sync is enabled and auto-refreshes to show you the status of when your project was last synced. You can also select this option to manually sync your projects.
Account
Email Address – Shows the email address logged in to Shapr3D.
Manage Account/Manage Subscription – Redirects you to the Shapr3D Subscription page in your browser.
Log Out – Logs you out of Shapr3D.
Access Settings
You can access Settings through any of the following ways:
From the Dashboard, select Settings.
From the modeling space, select Settings.
Shapr3D Settings
Account
Email Address – Shows the email address logged in to Shapr3D.
Log Out – Logs you out of Shapr3D.
Manage Subscription – Redirects you to the Shapr3D Subscription page in your browser.
Restore Subscription – Restores your previous subscription.
Preferences
Language – Choose your preferred supported language.
Theme – Choose your preferred theme: System, Light, Dark.
Start Shapr3D with – Select the screen that appears when you launch Shapr3D: Recents, Projects.
Interface – Choose between Left or Right to switch the placement of the menus and tools to the left-hand or right-hand side of your screen.
Show Menu Button Labels – Choose your preferred way to display the menu button labels:
Always – Menu labels are always displayed.
On Hover, On All Buttons as – The menu labels only display upon hovering your pointer.
Single Key Action – Enables Command Search or Hotkeys.
Customize keyboard shortcuts – Opens the Keyboard Shortcuts settings.
Circular Annotations – Choose between Always Radius or Radius and Diameter as your preferred annotation for circular sketches and geometry.
Navigation
2-Finger Rotation – Toggle to enable or disable 2-Finger Rotation.
Reverse Zoom Scroll Direction – Toggle to enable reverse zoom scroll direction. Note: If you're using a keyboard, visit Navigation Presets for more navigation controls.
Navigation Presets – Opens Navigation Presets.
Sync
Sync Across Devices – Toggle to enable or disable Sync.
Sync Projects – Appears when Sync is enabled and auto-refreshes to show you the status of when your project was last synced. You can also select this option to manually sync your projects.
Data Settings – Open to enable or disable Send Usage Data.
Account Deletion
Delete Account and Projects – Deletes your account and projects.
Important
This action cannot be undone. Once prompted, you will lose every project you worked on in Shapr3D.
Other device settings
Open the system settings of your iPadOS device, and find Shapr3D in the list of installed applications to access these additional settings:
Allow Shapr3D to Access – Enables access to specific device settings such as photos and camera.
Preferred Language – Another way to choose your preferred supported language.
Tutorial Mode – Enables Display Pencil and touches and Display keyboard presses. Restart Shapr3D for these changes to apply.
Access Preferences
To access Preferences, go to the Mac menu bar > Settings...
Shapr3D Settings
General
Language – Choose your preferred supported language.
Theme – Choose your preferred theme: System, Light, Dark.
Start Shapr3D with – Select the screen that appears when you launch Shapr3D: Recents, Projects.
Show Menu Button Labels – Choose your preferred way to display the menu button labels:
Always – Menu labels are always displayed.
On Hover, On All Buttons as – The menu labels only display upon hovering your pointer.
Single Key Action – Enables Command Search or Hotkeys.
Keyboard Shortcuts – Select Customize... to open the keyboard shortcuts settings.
Circular Annotations – Choose between Always Radius or Radius and Diameter as your preferred annotation for circular sketches and geometry.
View Navigation – Opens Navigation Presets.
Zoom – Toggle to enable Reverse scroll direction. Note: If you're using a keyboard, visit Navigation Presets for more navigation controls.
Tutorial Mode
Display clicks – Enable to display pointer clicks while modeling.
Display keyboard presses – Enable to display keyboard presses while modeling.
App Version – Check your software version.
Sync
Status – Select to Enable Across Devices or Disable Across Devices. When you enable Sync, the Sync Projects option appears and auto-refreshes to show you the status of when your project was last synced. You can also select this option to manually sync your projects.
Sync Projects – Appears when Sync is enabled and auto-refreshes to show you the status of when your project was last synced. You can also select this option to manually sync your project.
Account
Email Address – Shows the email address logged in to Shapr3D.
Log Out – Logs you out of Shapr3D.
Manage Subscription – Redirects you to the Shapr3D Subscription page in your browser.
Restore Subscription – Restores your previous subscription.
Delete Account and Projects – Deletes your account and project.
Important
This action cannot be undone. Once prompted, you will lose every project you worked on in Shapr3D.
