Screenshot tool

You can use the Screenshot tool to take clean snapshots of your model directly from the modeling space. Before capturing, you can customize how your model looks by adjusting visual elements like the grid, background, and body edges.

Use screenshots to:

• Capture quick visuals without UI elements
• Adjust visibility settings for clarity
• Save or copy images for presentations or feedback

How to take a screenshot

To take a screenshot:

1. Open your project.
2. Go to Export.
3. Under the Usage tab, select Image to open the Screenshot tool.
4. Select Next.
5. Use the menu to customize how you want your exported image to look:
   • Grid – Remove or keep the grid in the background.
   • Transparency – Make the background transparent or filled.
   • Body Edges – Render your project with or without edges.
     Note: You can also open the Items Manager to choose which items to display.
   • Resolution – Select the output size of your screenshot:
     • Actual - Captures the image at the current size of your workspace window.
     • Double - Doubles the pixel count of your current window for improved clarity.
     • Full HD - Exports at a standard 1920 x 1080 resolution.
     • 4K - Provides high-definition output at 3840 x 2160, suitable for professional presentations.
     • 8K - Delivers maximum detail at 7680 x 4320 for large-scale prints and high-fidelity renders.
6. To capture your model, select Capture .
7. In the Save dialog, enter a filename and choose where you want to save your captured image.
8. Select Save.

Copy and reuse your last screenshot setup

The Screenshot tool lets you quickly reuse and share the same captured view without setting it up again. Here's how it works:

• The tool remembers your last used settings, including grid, transparency, and edge visibility.
• Your saved settings are applied automatically when you reopen the tool.
• You can use a keyboard shortcut to copy your last screenshot without reopening the tool.
• The copied image is saved to your clipboard, ready to paste into emails, slides, or any document tool where you need to present your design.
