Parallel
Updated
Parallel lines have the same distance continuously between them. The Parallel constraint creates a parallel relationship between sketch line elements.
To create a Parallel constraint:
- Select two or more sketch lines on the same plane.
- From the constraints menu, select Parallel.
Learn more by watching the video below:
