Concentric

Concentric arcs share the same center point. You can use the Concentric icon-constraint-concentric.png constraint to create a concentric relationship between sketch arc elements.

To create a Concentric constraint:

  1. Select arc or circle elements.
  2. From the constraints menu, select Concentric.

Learn more by watching the video below:
