Adaptive user interface

Shapr3D has an adaptive user interface functionality that automatically recommends tools as you make selections in your projects. These tailored menus allow you to easily access everything you need without having to browse through the default menus. Taking advantage of the adaptive user interface can accelerate your workflow twice or thrice as much.

To use the adaptive user interface, pre-select elements in your project and then choose the tool icon-tools.pngyou need from the recommended tools.

Below are some examples of tools that get recommended based on your selections.

  Select a face   Offset Face icon-tools-offset-face.png becomes active
  Select a sketch profile   Extrude icon-tools-extrude.png becomes active
  Select a body   Move/Rotate icon-transform-move-rotate.png becomes active
  Select a sketch line or curve   Sketch mode icon-menu-sketch.png becomes active
  Select a line and a face   Rotate Around Axis icon-transform-rotate-around-axis.png becomes active.


Select a sketch profile and an axis



Revolve icon-tools-revolve.png becomes active.

In the example below, we select a body, and the Move/Rotate tool becomes active in the adaptive menu. From here, the body can be moved using the gizmo without having to interact with the menus.


As you continue to make selections, Shapr3D will further recommend tools.

For example, if you select two faces from different bodies, the adaptive menu provides access to tools such as Align and Replace Face, as shown below.


Tip

If you do not see the tool you are looking for directly in the adaptive menu, select More icon-generic-more.png to access additional functions that are valid for your selections.

adaptive-user-interface-more.pngBy taking advantage of the adaptive user interface, you can complete tasks without interacting with menus, significantly increasing your efficiency. You can also complete many of the tools accessed from the adaptive menu without having to select Done. To do this, simply select an empty area of the grid.

Read more

For detailed information about making selections in your projects visit Selecting geometry.
