Equal
Updated
The Equal constraint creates an equal length for selected lines and an equal radius for selected arcs and circles.
To create an Equal constraint:
- Select similar elements on the same sketch plane, such as multiple lines or multiple arcs.
- Select Equal from the constraints menu.
Learn more by watching the video below:
